EU-Schiff OBDSTAR DC706 ECU Tool Full Version mit MP001 Kit Support Car and Motorcycle ECM & TCM & BODY Clone by OBD or BENCH

Product Description

OBDSTAR DC706 ECU Tool Full Version mit MP001 Kit Support Car and Motorcycle ECM & TCM & BODY Clone by OBD or BENCH

The package includes OBDSTAR DC706 ECU Tool Full Version and MP001 KIT


OBDSTAR MP001 is the latest multifunctional programmer developed by OBDSTAR, which fully supports EEPROM/MCU read/write, clone, data processing functions for automotive, commercial vehicle, new energy vehicle, motorcycle, marine (jet-ski). MP001 is compatible with P003+ and has more SlMOS 18 than P003+(because the boot mode of SlMOS 18 is very special and needs more lO ports to be supported, P003+ has 4 lO ports and can't support it), and since MP001 has up to 12 lO ports, it can meet all future ECM requirements.

OBDSTAR MP001 Programmer can replace P003+, P003, P002 and P001 adapter totally, if you buy this kit, no need buy P003+ any more.


OBDSTAR DC706  Highlights

1. Stand-alone operation – No PC required.

2. Cost-effective – Similar to I/O Terminal but only about one-third of the price.

3. Wide module cloning support – BCM, ECU, TCU, RFH for cars and motorcycles.

4. Extensive ECU coverage – Includes MJD 8F2/8F3/6F3, IAW 8GF/8GSF/7GF/9GF/9GV/10GF, BMW MSD80/85/87, MSV80/90, GPEC2–GPEC4, Hyundai/Kia SIM2K series, VW/Audi Simos 18.x, Renault Siemens Sirius 34, GM Acdelco E39/E39A/E80/E84/E83/E90, Benz DSM/DSM222 (FBS4) and more.

5. Multiple connection modes – OBD, bench, and boot mode.

6. Advanced features – IMMO OFF, ISN reading, DSG mileage reset for DQ380/DQ500/DQ381, checksum correction.

7. User-friendly guidance – Step recording, wiring diagrams, and operation instructions shown on screen.

8. Frequent software updates – 1-year free; renewal discount if updated before expiry


Note:

• Does not clone VAG DQ250 before year 2008.

• P004 adapter is located in the second layer of the suitcase.

• Unable to add other functions, such as odometer correction, airbag reset, or key programming.

• Please register the device before use, following the OBDSTAR DC706 register manual (Distributor code: 0086A002).

• Language: English only.

• Please check the latest OBDSTAR DC706 car list(20260331) before purchase
  Please register the device before use, following the OBDSTAR DC706 manual (Distributor code: 0086A00200)

• OBDSTAR DC706 updates frequently — please update to the latest version before testing vehicles.

OBDSTAR DC706 ECU tool, with 1-year free upgrade, is designed for vehicle ECM, TCM and body/other system for ECU flasher. It can read ECU info, R/W Eeprom/Dflash/Pflash/MAP, reset ECU(Virgin), calibrate mileage, read IMMO pincode, ECU recovery... It's all by OBD or bench mode and makes ECU cloning easy.



Product Function:

ECU Clone/ All by OBD or Bench
ECM clone for cars(Bosch, Continental, Delphi, Denso, Magneti Marelli, Siemens...)
ECM clone for motorcycles(Bosch, Delphi, EFI...)
TCM clone(Ac Delco, Bosch, Continental, Getrag, GM, Kefico, Siemens, Temic, ZF...)
Body/Other clone(FCA, FIAT, FORD, GM/OPEL, LAND ROVER/JAGUAR, PSA, SMART, VOLVO...)


Supported ECU Manufacturers:

ALPS
Autoliv
Bosch
Continental
Delphi
Denso
Johnson Controls
Lear
Magneti Marelli
Siemens
Temic
Valeo

Supported Brands:

Car:

ASTON MARTIN
BMW
FAW
FCA(ALFA ROMEO, CHRYSLER, DODGE, FIAT...)
FORD/LINCOLN
GM/OPEL
HYUNDAI/KIA
LAND ROVER/JAGUAR
LUXGEN
MASERATI
MAZDA
MITSUBISHI
NISSAN
OPEL
PSA
SMART
SUBARU
SUZUKI
VOLVO
VW/AUDI/SEAT/SKODA


Motorcycle:

APRILIA
BRP
CFMOTO
DERBI
GILERA
GUZZI
PEUGEOT
PIAGGIO
QJBENELLI
VESPA




Advanced Functions:

1. R/W eeprom/dflash/pflash/Map, reset ECU(Virgin), calibrate mileage, read IMMO pincode, ECU recovery...
2. Support 710+ ECM types(Partial functions require P003 adapter.)
3. Support 210+ TCM types
4. Support 120+ body/other ECU types(AIRBAG, BCM, BSI, CEM, DDM/PDM, DIM, EPS, KeyLess(RFHUB/RFHM), KVM, RFA, SAM...)
5. Support VW DQXXX (TCM) calibrate mileage
6. Support motorcycle Delphi MT05, MT05.2, MT05.3 ECU clone
7. Support motorcycle BRP ME17.8.5 ECU clone (works with P003 adapter)
8. Support Piaggio series engine ECU clone(such as MIU G4 (M4G1))
9. Support intelligent search by brand, model, part No., ECU manufacturer, MCU controller type
10. Support automatic identification
11. Strong help data files
12. All by OBD or Bench mode

More functions are in developing...

Product Specifications:


Operation system	Android 5.1.1
CPU	RK3128 quad-core ARM cortex A7
Battery	3700mA, rechargeable polymer lithium battery
Extension memory card	32G micro SD (TF) card supported
Storage capacity	16GB
LCD	7.0 inch
LCD resolution	1024*600
Touch screen	Capacitive touch screen
Wifi	Supported
Working temperature	-20℃~55℃ (14℉~131℉)
Storage temperature	-20℃~70℃ (-4℉~158℉)
Weight	About 1.3kg
Dimension	243mm*148mm*36mm


Function Display:

1) Main Page/Brand Supported




2) ECM Clone for Cars






3) ECM Clone for Motorcycles



4) TCM Clone






5) Body/Other Clone






Package Includes:
1pc x DC706 tablet PC
1pc x 12V2A charger
1pc x M001
1pc x P004 adapter
1pc x BENCH-B V2 Cable
1pc x jumper wire
1pc x 3-in-1 jumper
1pc x Quick start guide/certificate
1pc x OBDSTAR MP001 Programmer
1pc x OBDSTAR C4-01 Host
1pc x W004 Read/Write soldering wire
1pc x W005 Read/Write soldering wire
1pc x OBDSTAR ECU Bench Jumper


---
